Product Overview
Features & Highlights
- Create beautiful and highly functional spaces that promote efficiency and productivity
- Integrate with worksurfaces, storage and accessories to create streamlined workstations
- Deliver power and data where they are needed
- Seamlessly integrate power and data as well as hang-on components and accessories
- Glass transoms or clerestory windows brighten the room with added daylight
- Custom graphics and field-applied film on glass provides endless opportunities for client personalization
- Specifiable in myriad materials, finishes, textures, colors and configurations
- Panel shells are available in solid materials, glass or a combination
- Solid material options range from tactile fabric to rich wood veneer to powdercoat paint
- Choose from sliding or swinging doors with frameless, framed or solid cores with hidden or exposed hardware
- Alternate cornice-height walls with full-height walls to provide an open feeling and enhance visual interest
Construction
- Panel width is 6"-60" (152.4-1524mm); restricted by wallcovering/substrate/glass width (laminate markerboard + tackable = 48" width or less)
- Butt-glazed glass panel width up to 120" (3048mm)
- Standard ceiling height up to 120" (3048mm)
- Standard frame depth 3.5" (88.9mm)
- Formaldehyde-free, fiber glass insulation installed in the factory in the frame and in the top distance channel
- SCS Indoor Advantage Gold Certified for Indoor Air Quality
- 44 to 48 STC for Combination Panels
- 810 Electrical System is a UL Listed Manufactured Wiring System evaluated to UL 183
- UL Listed plug and play factory assembled pre-wired electrical solution
Photos
Photos
Standard Finishes
Slight variations occur in texture, color, grain configurations and finish acceptance of materials used. Therefore, finished pieces may vary in tone or character from these images. Please order a sample from your KI sales representative for a more accurate representation of the finished piece.
Click here to view the Glass Finish Card.
1/4" Clear Tempered
1/4" Low Iron Clear Tempered
1/4" Clear Laminate
1/4" White Laminate
1/4" Light Satin Etch
1/4" Velour Satin Etch (1-Side)- 1/4" Velour Satin Etch (2-Sides)
3/8" Clear Tempered
3/8" Clear Laminate
3/8" White Laminate
1/2" Clear Tempered
1/2" Low Iron Clear Tempered
1/2" Clear Laminate w/ .030 Interlayer
1/2" Clear Laminate w/ .03 Acoustic Interlayer
1/2" Low Iron Clear Laminate w/ .030 Interlayer
Click here to view the Wood Veneer Finishes Card.
Anigre Clear
Cherry Storm on Beech
Cinnamon on Beech
Cocoa on Beech
Ebony Clear
Eclypse Black
Makore Clear
Monticello Maple on Beech
Natural on Beech
River Cherry on Beech
Zebrawood Clear
Cherry Storm on Maple
Cinnamon on Maple
Cocoa on Maple
Kensington Maple on Maple
Monticello Maple on Maple
River Cherry on Maple
Brighton Walnut on Oak
Castle Oak on Oak
Cinnamon on Oak
Cocoa on Oak
Medium on Oak
River Cherry on Oak
Natural on Walnut
Click here to view Architectural Wall Shells & Trim Card.
Birch Bark
Biscotti
Biscotti Textured
Black Pearl Metallic
Bronze Metallic
Bronze Metallic Textured
Calm Before the Storm
Calm Before the Storm Textured
Cashmere
Champagne Metallic
Cool Grey
Cottonwood
Cottonwood Textured
Creamy White
Cultured Pearl
Eclipse
Eclipse Textured
Espresso Metallic
Flannel
Flannel Textured
Full Moon
Light Tone
Light Tone Textured
Misty Brown
Neutral Ground
Neutral Ground Textured
Sand
Sand Textured
Satin Sheet
Satin Sheet Textured
Starlight Silver Metallic
Steel Wool
Steel Wool Textured
Warm Grey
Warm Grey Textured
Wet Sand
Wet Sand Textured
Black
Clear Anodized Aluminum
Silver Anodized Aluminum
Axiom
Basis
Business Casual
Busmanti
Calculation
Diago
Freehand
Glissade
Graph
Gridlock
Hopscotch
Horizon Line
Ion
Learning the Ropes
Lex
New Twist
Oasis
Parameter
Park
Popcorn
Prism
Rattan
Reciprocal
Ripple Effect
Shifting Sand
Sillio
Spectrum
Square Off
Theorum
Topstitch
Travertine
Vortex
Anodized Grey
Black
Champagne
Cottonwood
Light Tone
Seagull White
Warm Grey
Product Story
The basic task of a wall is to segment space and provide privacy. Genius® architectural wall does that and more, creating highly functional spaces that promote efficiency and productivity.
Genius architectural wall easily accommodates those needs through customizable designs and configurations. Compatible with all KI systems furniture lines, Genius architectural wall integrates with worksurfaces, storage and accessories to create streamlined workstations, conference rooms, training rooms and more.
With an unlimited offering of options, materials, textures, colors, door styles and configurations, Genius architectural wall offers the design flexibility to create unmatched visual impact. From offices to conference rooms to storefronts, Genius architectural wall has the product depth to achieve any look in any environment. Frames can be specified in materials ranging from anodized aluminum to solid wood. Choose from glass or veneer, sliding or swinging doors with hidden or exposed hardware. The range of options eliminates boundaries on what designs are possible.
Genius architectural wall transforms indoor spaces while preserving the outdoor environment. Constructed using ecologically sound materials and manufacturing processes, Genius architectural walls are designed for sustainability. Genius architectural wall helps minimize the office footprint using a variety of sliding doors. Additionally, glass options easily bring daylight into interior spaces. In addition, Genius architectural wall can significantly reduce construction landfill debris from a job site while maintaining higher levels of indoor air quality.
Genius architectural wall offers the high performance and value demanded by today's offices and professional environments. With a full offering of features and options, Genius can reduce noise (44 to 48 STC on solid panels), deliver power and data, and seamlessly integrate with furniture and architectural elements. Designed for durability, Genius architectural wall provides years of use, even through multiple reconfigurations.
Approved for seismic areas and cleanroom applications. 10-year warranty on most items.
